PRODUCTS \ IP Cameras \ Camera With Pan,Zoom \ DYN-615


Item
: IP Camera
Item code: DYN-631
Download PDF file



SPECIFICATIONS

Hardware performance
Product type IP camera
Operation system Embedded operating system

Web environment

Web protocol TCP/IP, UDP/IP, HTTP, SMTP, FTP, DHCP, DDNS, UPNP, NTP, RTSP, ONVIF
LAN port 10Base-T/100Base-TX
Wifi WIFI,802.11 b/g/n

Image performance

Resolution VGA; QVGA; QQVGA
Compression mode M-JPEG
Max frame rate 30fps

Other parameters

Lens f=3.6mm, F=2.0
Min. illumination IR on, 0 Lux
Electronic shutter 1/50s(1/60s)-1/100,000 s
SNR 48db
Safety performance Three levels of user rights
Install mode Wall-mounted
Other performance PC software, support for Microsoft Windows 98/2000/XP/Vista/Windows 7/Mac OS,And the
Internet Explorer6.1 and above version or browser compatibility, Firefox, etc., provide
iSmartViewPro client software
Power supply DC 5V
Sensor CMOS Sensor
IP camera performance Support video control, Two-way voice talkback, motion detection, external alarm(sends information to alarm the server by Email, FTP); Manufacturers provide free DDNS, and has been written into equipment; 18pcs IR LEDs, up to 15meters night vision; automatically control through the photoresistor;
Audio input None
Audio output None
Alarm in Not supported
Alarm out Not supported
Power consumption Power<6W

Appearance parameters

Body size 153*96*96mm
Product weight 0.53kg

Environment parameters

Environment temperature
-10℃--50℃
Environment humidity
below 85% RH
