PRODUCTS \ LAN Products \ Switches 10/100Mbps \ SW240010-RV


Item: 24 Port 10/100Mbps Ethernet Switch
Item code: SW240010-RV
Download PDF file    Download Packaging file



DESCRIPTION
The new Dynamode 24-Port 10/100Mbps Fast Switch is an ideal upgrade or Hardware replacement for your current or future LAN (Local Area Network). Featuring our class-leading ASIC core processor which allows efficient network data transfer, even under heavy load cycles. Running industry standard Ethernet (10Mbps) and Fast Ethernet (100Mbps), the Switch is also capable of running full duplex mode, thus achieving double up to 200Mbps to your Network.
Robust in design, the 24-Port 10/100Mbps Ethernet Switch is just 1U high and is ideal for both Rack-mount and Desktop placement and with silent cooling means it can be placed in noise sensitive locations. Benefiting from a metal enclosure and full STP (shielded) RJ45 ports also means is it ideal for critical applications as well as placement in less than ideal conditions. Energy efficient design also means less Power Consumption to help you reduce costs and lower your Carbon Footprint.

FEATURES
24-Port 10/100Mbps auto-sensing RJ45 Ports
Fully 802.3 and 802.3u Fast Ethernet compliant
Wire-speed Packet filtering for improved LAN speeds
Supports Pre-802.3az Energy Efficient Ethernet ability
Reduce your Power Consumption and Carbon Footprint
Enhanced ASIC core enable up to 3.57Mbps Packet Forwarding
Supports non-blocking 'Store and Forward'  packet routing for fast access
Built-in Memory Buffers with up to 2MB Buffer and up to 8Mbyte MAC    addressing
1U high and 19" width in RFI protected enclosure with passive cooling
Supplied with Rack-mount Kit (19" Mounting)

SPECIFICATIONS

Standards and Protocols IEEE802.3, 802.3u, 802.3ab, 802.3z, 802.3x
Basic Function

CSMA/CD Ethernet 'Store and Forward' and 'Cut Through' Packet Delivery

MAC Address Table

8k Routing Address Table, ASIC Core

Transmission Method 'Store and Forward' and 'Cut Through' Packet Delivery
Ports 24-Port 10/100Mbps auto-negotiation
Full and Half Duplex, up to 200Mbps connection speeds
RJ-45 (STP), Auto MDI/MDIX on all Ports
Network Media 10/100BaseT: UTP category 3, 4, 5, 5e, 6 (maximum 100 metres)
EIA/TIA-568 100 Ohm Cabling, UTP or STP
LED Indicators Power, Link, Speed
Safety and Emissions
CE, FCC
Environment Operating temperature: 0°C-40°C (32°F-104°F)
Storage temperature: -40°C-70°C (-40°F- 158°F)
Relative Humidity: 10%-90%, non-condensing
Storage Humidity: 5%-95% non-condensing
Power 100-240VAC, 50/60Hz auto switching
