PRODUCTS \ LAN Products \ Switches Gigabit \ SW800010-D


Item: 8 Port 10/100/1000Mbps Gigabit Switch
Item code: SW800010-D
Download PDF file   Download Packaging file

FEATURES
Built-in 8 Ports Gigabit Ethernet
Up to x10 performance of Fast Ethernet
Backward 100Mbps and 10Mbps Networks
Desktop design with silent operation
Ideal for Business and Home Users looking for increased Network    performance
Improve Internet, Multimedia, Video Streaming and application performance
Easy Uplink on any Switch - No Special lead needed
Stylish and compact design with Low Power Consumption
Plug n' Play for all Computers, Media Centres, Game Consoles and more



SPECIFICATIONS

Standards IEEE 802.3 10 Base-T ethernet
IEEE 802.3a 100 Base-TX fast ethernet
IEEE 802.3ab 1000 Base-T gigabit
IEEE 802.3x flow control
MAC Address Table 8K
Data transfer rate Ethernet: 10Mbps (Half-duplex)
20Mbps (Full-duplex)
Fast Ethernet: 100Mbps (Half-duplex)
200Mbps (Full-duplex)
Gigabit Ethernet:2000Mbps (Full-duplex)
Network cables Ethernet: 2-pair UTP Cat. 3,4,5, Unshield
Twisted Pair (UTP )Cable
Fast Ethernet: 2-pair UTP Cat. 5, Unshield
Twisted Pair (UTP )Cable
Gigabit Ethernet: 4-pair UTP Cat. 5, Unshield
Twisted Pair (UTP )Cable
Ports 8×10/100/1000 Mbps auto-MDI/MDIX ports
EXTERNAL POWER SUPPLY 5VDC/1A
Power consumption 3watts(maximum)
Temperature
Operating Temperature: -10℃~45℃(14℉~113℉);
Storage Temperature: -15℃~60℃ (5℉~140℉);
Humidity 5 to 95% RH, non-condensing
Operating Humidity: 10%~90% non-condensing;
Storage Humidity: 5%~90% non-condensing
Forwarding mode Store and Forward
LED Power,100/1000Mbps Link/Act
